Slide-in vacuum tanks are the perfect choice for getting started in the business, as a backup unit, or for scenarios when a smaller tank is required such as events or in tight urban areas. A slide-in pumper tank can be mounted on different transportation vehicles including pickup trucks, flatbed trucks, and trailers. We offer custom slide-in vacuum tanks as well as two standard stock options.
Built with the same high standards of quality as our full size tanks, our custom slide-in pumper tanks are made from 304L stainless steel to offer the highest durability. Have peace of mind in your investment knowing that these slide-in pumper tanks will last for the long haul.
Customization the way you need it
Features & Options
Explore the features and options available for our slide-in vacuum tanks.
Model GH450 – 300 Waste & 150 Fresh Water
- All 304 stainless steel metal (no secondary or out of spec material)
- Honda 5.5hp electric start engine w/battery
- Conde super 6 vacuum/pressure pump (90 cfm)
- Toico water pump (35 psi)
- 30 foot of wash-down hose
- Stainless steel hose hooks
- 304 stainless steel primary
- 304 stainless steel secondary shut-off
- Pressure relief valve
- Vacuum relief valve
- 2 – 2 inch sight glasses on waste compartment
- ¾ inch sight tube on fresh water compartment
- 2 inch suction inlet
- 2 inch x 30ft tiger-tail (hi-vac) suction hose with suction wand
- Stainless steel suction hose hooks
- 3″ dump valve with dump sump, 10ft dump hose and quick coupling
- Stainless steel lifting hooks
MODEL GH650 – 400 Waste & 250 Water
- All 304 stainless steel metal (no secondary or out of spec material)
- Honda 5.5hp electric start engine w/battery
- Conde super 6 vacuum/pressure pump (90 cfm)
- Toico water pump (35 psi)
- 30 foot of wash-down hose
- Stainless steel hose hooks
- 1 ½ inch water dump
- 304 stainless steel primary
- 304 stainless steel secondary shut-off
- Pressure relief valve
- Vacuum relief valve
- 2 – 2 inch sight glasses on waste compartment
- ¾ inch sight tube on fresh water compartment
- 2 inch suction inlet
- 2 inch x 30ft tiger-tail (hi-vac) suction hose with suction wand
- Stainless steel suction hose hooks
- 3″ dump valve with dump sump, 10ft dump hose and quick coupling
- Stainless steel lifting hooks
- Custom Tank Size and Split
- Conde SDS 6 (115 cfm)
- Masport HXL3 (112 cfm)
- 2” x 50’ Tiger Tail Hose
- Dual 2” Suction
- Custom placement of pump platform – or no platform
- Custom hose hook location
